6×4 P Light Product Image

6×4 P Light

Extremely functional and customizable to get the job done.

Features

  • ​Powerful lighting output perfect for fire and EMS apparatuses
  • LED Available in single, dual, and split colors
  • Available for use as backup, backup with warning, stop/tail/turn, turn and warning
  • Lens available in clear, red, blue, green or amber
  • Traditional polycarbonate lens
  • Rugged, weather-resistant IP67 enclosure
  • Industry standard bolt pattern location

Customer support with unmatched can-do attitude

Tech Specs

  • INPUT VOLTAGE RANGE

    9-32 Vdc

  • DIMENSIONS (WITHOUT BEZEL)

    6.4" L x 3.9" H x 1.0" D

  • AVAILABLE LED COLORS

    All standard single, dual, or split color warning, red stop/tail, amber turn, white backup or white backup with amber, blue, green, red or white warning

  • AVAILABLE LENS COLORS

    Clear, red, blue, green or amber

  • FLASH PATTERNS

    15 warning and backup with warning, 4 sequential turn patterns, plus steady burn on turn and 1 flicker stop on stop/tail

  • CERTIFICATIONS

    SAE J595 Class 1, SAE J595 Class 2 (low power double flash), SAE J595 Class 3 (Green), CA Title 13, NFPA, KKK-1822-F and FMVSS-108 (backup, stop/tail, turn)

  • MOUNT

    Stud or screw mount

Resources

Part Numbers

Symbol Key Descriptions:

††
This symbol next to a part means this part number is Going Obsolete. Check availability with customer service.
This symbol next to a part means No Discounts Allowed. Contact customer service if you have any questions.
PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
EPSSB0PQ0-D 6x4 P Backup Light w/ Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Red/White 5 Years $269
EPSSB0JWZ-A 6X4 P Warning Light w/ Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Amber 5 Years $258
EPSSB0JX6-R 6x4 P Stop/Tail & Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 20 LED - Red 5 Years $213
EPSSB0PQ0-E 6x4 P Backup Light w/ Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Blue/White 5 Years $269
EPSSB0PQ0-F 6x4 P Backup Light w/ Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Amber/White 5 Years $269
EPSSB0QFU-D 6x4 P Backup Light w/ Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Red/White 5 Years $269
EPSSB0QFU-E 6x4 P Backup Light w/ Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Blue/White 5 Years $269
EPSSB0QFU-F 6x4 P Backup Light w/ Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 28 LED, Amber/White 5 Years $269
EPSSB0TFE-E 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Blue/White 5 Years $288
EPSSB0JWZ-B 6X4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Blue 5 Years $258
EPSSB0JWZ-G 6X4 P Warning Light, Screw Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Green 5 Years $258
EPSSB0JWZ-R 6X4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Red 5 Years $258
EPSSB0JWZ-W 6X4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - White 5 Years $258
EPSSB0JX1-A 6X4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Amber 5 Years $258
EPSSB0TFE-F 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Amber/White 5 Years $288
EPSSB0TFE-M 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Blue/Amber 5 Years $288
EPSSB0JX4-R 6X4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Red 5 Years $258
EPSSB0JX5-W 6x4 P Backup Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - White 5 Years $213
EPSSB0JX7-R 6x4 P Stop/Tail & Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Red Lens, 20 LED - Red 5 Years $213
EPSSB0JX8-A 6x4 P Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 20 LED - Amber 5 Years $213
EPSSB0JX9-A 6x4 P Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Amber Lens, 20 LED - Amber 5 Years $213
EPSSB0JXA-A 6X4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Amber 5 Years $258
EPSSB0JXA-B 6X4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Blue 5 Years $258
EPSSB0JXA-G 6X4 P Warning Light, Stud Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Green 5 Years $258
EPSSB0JXA-R 6X4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Red 5 Years $258
EPSSB0JXA-W 6X4P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - White 5 Years $258
EPSSB0JXB-A 6X4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Amber 5 Years $258
EPSSB0JXC-B 6X4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Blue 5 Years $258
EPSSB0JXD-G 6X4 P Warning Light, Stud Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Green 5 Years $258
EPSSB0JXE-R 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Red 5 Years $258
EPSSB0JXF-W 6x4 P Backup Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - White 5 Years $213
EPSSB0JXG-R 6x4 P Stop/Tail & Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 20 LED - Red 5 Years $213
EPSSB0JXH-R 6x4 P Stop/Tail & Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Red Lens, 20 LED - Red 5 Years $213
EPSSB0JXJ-A 6x4 P Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 20 LED - Amber 5 Years $213
EPSSB0JXK-A 6x4 P Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Amber  Lens, 20 LED - Amber 5 Years $213
EPSSB0TFD-J 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Dual Color, Red/Blue 5 Years $330
EPSSB0TFD-F 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Dual Color, Amber/White 5 Years $330
EPSSB0TFD-E 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Dual Color, Blue/White 5 Years $330
EPSSB0TFC-M 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Split Color, Blue/Amber 5 Years $288
EPSSB0TFD-D 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Dual Color, Red/White 5 Years $330
EPSSB0JX3-G 6X4 P Warning Light, Screw Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Green 5 Years $258
EPSSB0TFC-E 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Blue/White 5 Years $288
EPSSB0TFC-F 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Split Color, Amber/White 5 Years $288
EPSSB0TFC-J 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Split Color, Red/Blue 5 Years $288
EPSSB0TFC-K 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Split Color, Red/Amber 5 Years $288
EPSSB0TFC-D 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Red/White 5 Years $288
EPSSB0TFB-F 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Dual Color, Red/Blue 5 Years $330
EPSSB0TFB-E 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Dual Color, Blue/White 5 Years $330
EPSSB0TFB-D 6x4 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED Dual Color, Red/White 5 Years $330
EPSSB0TFE-K 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Red/Amber 5 Years $288
EPSSB0TFE-J 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Red/Blue 5 Years $288
EPSSB0TFE-D 6x4 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Volt SAE with 1.5' Pigtail, Clear Lens, 24 LED, Split Color, Red/White 5 Years $288
EPSSB0JX2-B 6x4 P Warning Light,  Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 12 LED, Single Color - Blue 5 Years $258

Accessories

PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
PPS7BZL01C Chrome Single Bezel (includes gasket & hardware) for use with 6x4 P Lights 5 Years $50
PPS7BZL01B Black Single Bezel (includes gasket & hardware) for use with 6x4 P Lights 5 Years $50

Service Parts

PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
†† PPS8HK01-SM Hardware Kit for Screw Mount application 2 Years $27
PPS8HK01-BZ Hardware Kit for Screw Mount application, Chrome 5 Years $40
PPS8HK02-BZ Hardware Kit for Screw Mount application, Black 5 Years $40
PPS8HK01-ST Hardware Kit for Screw Mount application 2 Years $6
