7×3 P Light Product Image

7×3 P Light

Extremely functional and customizable to get the job done.

Features

  • ​Powerful lighting output perfect for fire and EMS apparatuses
  • Available for use as backup, backup with warning, stop/tail/turn, turn and warning
  • Lens available in clear, red, blue, green or amber
  • Traditional polycarbonate lens
  • Rugged, weather-resistant IP67 enclosure
  • Industry standard bolt pattern location

Customer support with unmatched can-do attitude

Tech Specs

  • INPUT VOLTAGE RANGE

    9-32 Vdc

  • DIMENSIONS (WITHOUT BEZEL)

    7.25" L x 3.1" H x 1.0" D

  • AVAILABLE LED COLORS

    All standard single color warning, red stop/tail, amber turn, white backup or white backup with amber, blue, green, red or white warning

  • AVAILABLE LENS COLORS

    Clear, red, blue, green or amber

  • FLASH PATTERNS

    15 warning and backup with warning, 3 sequential turn patterns, plus steady burn on turn and 1 flicker stop on stop/tail

  • CERTIFICATIONS

    SAE J595 Class 1, SAE J595 Class 2 (low power double flash), SAE J595 Class 3 (Green), CA Title 13, NFPA, KKK-1822-F and FMVSS-108 (backup, stop/tail, turn)

  • MOUNT

    Stud or screw mount

Resources

Part Numbers

Symbol Key Descriptions:

††
This symbol next to a part means this part number is Going Obsolete. Check availability with customer service.
This symbol next to a part means No Discounts Allowed. Contact customer service if you have any questions.
PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
EPSSC0PPZ-F 7x3 P Backup Light w/Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Amber/White 5 Years $215
EPSSC0JY4-R 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Red 5 Years $215
EPSSC0PPZ-E 7x3 P Backup Light w/Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Blue/White 5 Years $215
EPSSC0JXS-A 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Amber 5 Years $215
EPSSC0JXS-B 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Blue 5 Years $215
EPSSC0JXS-G 7x3 P Warning Light, Stud Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Green 5 Years $215
EPSSC0JXS-R 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Red 5 Years $215
EPSSC0JXS-W 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - White 5 Years $215
EPSSC0JXU-A 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Amber Lens, 12 LED, Single Color - Amber 5 Years $215
EPSSC0JXV-B 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Blue Lens, 12 LED, Single Color - Blue 5 Years $215
EPSSC0JXX-G 7x3 P Warning Light, Stud Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Green Lens, 12 LED, Single Color - Green 5 Years $215
EPSSC0JXY-R 7x3 P Warning Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Red Lens, 12 LED, Single Color - Red 5 Years $215
EPSSC0JXZ-W 7x3 P Backup Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - White 5 Years $170
EPSSC0JY0-R 7x3 P Stop/Tail & Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - Red 5 Years $170
EPSSC0JY1-R 7x3 P Stop/Tail & Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Red Lens, 18 LED - Red 5 Years $170
EPSSC0JY2-A 7x3 P Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - Amber 5 Years $170
EPSSC0JY3-A 7x3 P Turn Light, Stud Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Colored Lens, 18 LED - Amber 5 Years $170
EPSSC0JY4-A 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Amber 5 Years $215
EPSSC0JY4-B 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Blue 5 Years $215
EPSSC0JY4-G 7x3 P Warning Light, Screw Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - Green 5 Years $215
EPSSC0JY4-W 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 12 LED, Single Color - White 5 Years $215
EPSSC0JY5-A 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Amber Lens, 12 LED, Single Color - Amber 5 Years $215
EPSSC0JY6-B 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Blue Lens, 12 LED, Single Color - Blue 5 Years $215
EPSSC0JY7-G 7x3 P Warning Light, Screw Mount, SAE J595 Class 3, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Green Lens, 12 LED, Single Color - Green 5 Years $215
EPSSC0JYA-W 7x3 P Backup Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - White 5 Years $170
EPSSC0JYB-R 7x3 P Stop/Tail & Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - Red 5 Years $170
EPSSC0JYC-R 7x3 P Stop/Tail & Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Red Lens, 18 LED - Red 5 Years $170
EPSSC0JYD-A 7x3 P Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Lens, 18 LED - Amber 5 Years $170
EPSSC0JYE-A 7x3 P Turn Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Amber Lens, 18 LED - Amber 5 Years $170
EPSSC0PPZ-D 7x3 P Backup Light w/Warning, Screw Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Red/White 5 Years $215
EPSSC0QFW-D 7x3 P Backup Light with Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Red/White 5 Years $215
EPSSC0QFW-E 7x3 P Backup Light with Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Blue/White 5 Years $215
EPSSC0QFW-F 7x3 P Backup Light with Warning, Stud Mount, SAE J595 Class 1, CA Title 13 certified, NFPA, KKK-1822-F, FMVSS-108, 9-32 Vdc, 1.5' Pigtail, Clear Housing/Lens, 28 LED, Amber/White 5 Years $215
EPSSC0JY8-R 7x3 P Warning Light, Screw Mount, SAE J595 Class 1, CA Title 13, NFPA, KKK-1822-F, 9-32 Vdc, 1.5' Pigtail, Red Lens, 12 LED, Single Color - Red 5 Years $215

Accessories

PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
PPS8BZL01C Chrome Single Bezel (includes gasket & hardware) for use with 7x3 P Lights 5 Years $45
PPS8BZL01B Black Single Bezel (includes gasket & hardware) for use with 7x3 P Lights 5 Years $45

Service Parts

PART NUMBER DESCRIPTION WARRANTY UNIT PRICE
PPS8HK02-BZ Hardware Kit for Screw Mount application, Black 5 Years $35
PPS8HK01-SM Hardware Kit for Screw Mount application 2 Years $24
PPS8HK01-ST Hardware Kit for Screw Mount application 2 Years $5
PPS8HK01-BZ Hardware Kit for Screw Mount application, Chrome 5 Years $35
